File:Suckale08 fig3 glucose insulin day.jpg

The idealised diagram shows the fluctuation of blood sugar (red) and the sugar-lowering hormone insulin (blue) in humans during the course of a day containing three meals. In addition, the effect of a sugar-rich versus a starch-rich meal is highlighted.


Insulin is a hormone which has extensive effects on metabolism and other body functions, such as vascular compliance. Insulin causes cells in the liver, muscle, and fat tissue to take up glucose from the blood, storing it as glycogen in the liver and muscle, and stopping use of fat as an energy source. When insulin is absent (or low), glucose is not taken up by body cells, and the body begins to use fat as an energy source, for example, by transfer of lipids from adipose tissue to the liver for mobilization as an energy source. As its level is a central metabolic control mechanism, its status is also used as a control signal to other body systems (such as amino acid uptake by body cells). It has several other anabolic effects throughout the body. When control of insulin levels fails, diabetes mellitus results.

Insulin is used medically to treat some forms of diabetes mellitus. Patients with Type 1 diabetes mellitus depend on external insulin (most commonly injected subcutaneously) for their survival because the hormone is no longer produced internally. Patients with Type 2 diabetes mellitus are insulin resistant, and because of that, may suffer from a relative insulin deficiency; some patients with Type 2 diabetes may eventually require insulin when other medications fail to control blood glucose levels adequately.

Insulin is a peptide hormone composed of 51 amino acid residues and has a molecular weight of 5808 Da. It is produced in the islets of Langerhans in the pancreas. The name comes from the Latin insula for "island".

Insulin's structure varies slightly between species of animal. Insulin from animal sources differs somewhat in 'strength' (i.e., in carbohydrate metabolism control effects) in humans because of those variations. Porcine (pig) insulin is especially close to the human version.

Gene[]

The proinsulin precursor of insulin is encoded by the INS gene.[1][2]

Alleles[]

A variety of mutant alleles with changes in the coding region have been identified. There is a read-through gene, INS-IGF2, which overlaps with this gene at the 5' region and with the IGF2 gene at the 3' region.[1]

Regulation[]

There are several regulatory sequences in the promoter region of the human insulin gene, to which transcription factors bind.

In general, the A-boxes bind to Pdx1 factors, E-boxes bind to NeuroD, C-boxes bind to MafA and cAMP response elements to CREB.

There are also silencers that inhibit transcription.

Regulatory sequences and their transcription factors for the insulin gene.[3]
Regulatory sequence binding transcription factors
ILPR Par1
A5 Pdx1
negative regulatory element (NRE)[4] glucocorticoid receptor, Oct1
Z (overlapping NRE and C2) ISF
C2 Pax4, MafA(?)
E2 USF1/USF2
A3 Pdx1
CREB RE -
CREB RE CREB, CREM
A2 -
CAAT enhancer binding (CEB) (partly overlapping A2 and C1) -
C1 -
E1 E2A, NeuroD1, HEB
A1 Pdx1
G1 -

Protein structure[]

See also: Insulin/IGF/Relaxin family

Within vertebrates, the similarity of insulins is extremely close. Bovine insulin differs from human in only three amino acid residues, and porcine insulin in one. Even insulin from some species of fish is similar enough to human to be clinically effective in humans. Insulin in some invertebrates (eg, the Caenorhabditis elegans nematode) is quite close to human insulin, has similar effects inside cells, and is produced very similarly. Insulin has been strongly preserved over evolutionary time, suggesting its centrality in animal metabolic control. The C-peptide of proinsulin (discussed later), however, differs much more amongst species; it is also a hormone, but a secondary one.

Synthesis, physiological effects, and degradation[]

Synthesis[]

Insulin is produced in the pancreas, and released when any of several stimuli are detected. These include protein ingestion, and glucose in the blood (from food which produces glucose when digested -- characteristically this is carbohydrate, though not all types produce glucose and so an increase in blood glucose levels). In target cells, they initiate a signal transduction which has the effect of increasing glucose uptake and storage. Finally, insulin is degraded, terminating the response.

Insulinpath

Insulin undergoes extensive posttranslational modification along the production pathway. Production and secretion are largely independent; prepared insulin is stored awaiting secretion. Both C-peptide and mature insulin are biologically active. Cell components and proteins in this image are not to scale.

In mammals, insulin is synthesized in the pancreas within the beta cells (β-cells) of the islets of Langerhans. One million to three million islets of Langerhans (pancreatic islets) form the endocrine part of the pancreas, which is primarily an exocrine gland. The endocrine portion only accounts for 2% of the total mass of the pancreas. Within the islets of Langerhans, beta cells constitute 60–80% of all the cells.

In beta cells, insulin is synthesized from the proinsulin precursor molecule by the action of proteolytic enzymes, known as prohormone convertases (PC1 and PC2), as well as the exoprotease carboxypeptidase E.[5] These modifications of proinsulin remove the center portion of the molecule (ie, C-peptide), from the C- and N- terminal ends of proinsulin. The remaining polypeptides (51 amino acids in total), the B- and A- chains, are bound together by disulfide bonds/disulphide bonds. Confusingly, the primary sequence of proinsulin goes in the order "B-C-A", since B and A chains were identified on the basis of mass, and the C peptide was discovered after the others.

The endogenous production of insulin is regulated in several steps along the synthesis pathway:

It has been shown that insulin and its related proteins, are also produced inside the brain and that reduced levels of these proteins are linked to Alzheimer's disease.[6][7][8]

Release[]

See also: Blood glucose regulation

Beta cells in the islets of Langerhans release insulin in two phases. The first phase insulin release is rapidly triggered in response to increased blood glucose levels. The second phase is a sustained, slow release of newly formed vesicles that are triggered independently of sugar. The description of first phase release is as follows:

  • Glucose enters the beta cells through the glucose transporter GLUT2
  • Glucose goes into the glycolysis and the respiratory cycle where multiple high-energy ATP molecules are produced by oxidation
  • Dependent on ATP levels, and hence blood glucose levels, the ATP-controlled potassium channels (K+) close and the cell membrane depolarizes
  • On depolarization, voltage controlled calcium channels (Ca2+) open and calcium flows into the cells
  • An increased calcium level causes activation of phospholipase C, which cleaves the membrane phospholipid phosphatidyl inositol 4,5-bisphosphate into inositol 1,4,5-triphosphate and diacylglycerol.
  • Inositol 1,4,5-triphosphate (IP3) binds to receptor proteins in the membrane of endoplasmic reticulum (ER). This allows the release of Ca2+ from the ER via IP3 gated channels, and further raises the cell concentration of calcium.
  • Significantly increased amounts of calcium in the cells causes release of previously synthesized insulin, which has been stored in secretory vesicles

This is the main mechanism for release of insulin. In addition some insulin release takes place generally with food intake, not just glucose or carbohydrate intake, and the beta cells are also somewhat influenced by the autonomic nervous system. The signaling mechanisms controlling these linkages are not fully understood.

Other substances known to stimulate insulin release include amino acids from ingested proteins, acetylcholine, released from vagus nerve endings (parasympathetic nervous system), cholecystokinin[How to reference and link to summary or text], released by enteroendocrine cells of intestinal mucosa and glucose-dependent insulinotropic peptide (GIP). Three amino acids (alanine, glycine and arginine) act similarly to glucose by altering the beta cell's membrane potential. Acetylcholine triggers insulin release through phospholipase C, while the last acts through the mechanism of adenylate cyclase.

The sympathetic nervous system (via Alpha2-adrenergic stimulation as demonstrated by the agonists clonidine or methyldopa) inhibit the release of insulin. However, it is worth noting that circulating adrenaline will activate Beta2-Receptors on the Beta cells in the pancreatic Islets to promote insulin release. This is important since muscle cannot benefit from the raised blood sugar resulting from adrenergic stimulation (increased gluconeogenesis and glycogenolysis from the low blood insulin: glucagon state) unless insulin is present to allow for GLUT-4 translocation in the tissue. Therefore, beginning with direct innervation, norepinephrine inhibits insulin release via alpha2-receptors, then subsequently, circulating adrenaline from the adrenal medulla will stimulate beta2-receptors thereby promoting insulin release.

When the glucose level comes down to the usual physiologic value, insulin release from the beta cells slows or stops. If blood glucose levels drop lower than this, especially to dangerously low levels, release of hyperglycemic hormones (most prominently glucagon from Islet of Langerhans' alpha cells) forces release of glucose into the blood from cellular stores, primarily liver cell stores of glycogen. By increasing blood glucose, the hyperglycemic hormones correct life-threatening hypoglycemia. Release of insulin is strongly inhibited by the stress hormone norepinephrine (noradrenaline), which leads to increased blood glucose levels during stress.

Evidence of impaired first phase insulin release can be seen in the glucose tolerance test, demonstrated by a substantially elevated blood glucose level at 30 minutes, a marked drop by 60 minutes, and a steady climb back to baseline levels over the following hourly timepoints.

Oscillations[]

Main article: Insulin release oscillations
File:Pancreas insulin oscillations.svg

Insulin release from pancreas oscillates with a period of 3–6 minutes.[9]

Even during digestion, generally one or two hours following a meal, insulin release from pancreas is not continuous, but oscillates with a period of 3–6 minutes, changing from generating a blood insulin concentration more than ~800 pmol/l to less than 100 pmol/l.[9] This is thought to avoid downregulation of insulin receptors in target cells and to assist the liver in extracting insulin from the blood.[9] This oscillation is important to consider when administering insulin-stimulating medication, since it is the oscillating blood concentration of insulin release which should, ideally, be achieved, not a constant high concentration.[9] It is also important to consider in that all methods of insulin replacement can never hope to replicate this delivery mechanism precisely. This may be achieved by delivering insulin rhythmically to the portal vein or by islet cell transplantation to the liver.[9] Future insulin pumps could attempt to address this characteristic. (See also Pulsatile Insulin.)

Signal transduction[]

There are special transporter proteins in cell membranes through which glucose from the blood can enter a cell. These transporters are, indirectly, under blood insulin's control in certain body cell types (e.g., muscle cells). Low levels of circulating insulin, or its absence, will prevent glucose from entering those cells (e.g., in Type 1 diabetes). However, more commonly there is a decrease in the sensitivity of cells to insulin (e.g., the reduced insulin sensitivity characteristic of Type 2 diabetes), resulting in decreased glucose absorption. In either case, there is 'cell starvation', weight loss, sometimes extreme. In a few cases, there is a defect in the release of insulin from the pancreas. Either way, the effect is, characteristically, the same: elevated blood glucose levels.

Activation of insulin receptors leads to internal cellular mechanisms that directly affect glucose uptake by regulating the number and operation of protein molecules in the cell membrane that transport glucose into the cell. The genes that specify the proteins that make up the insulin receptor in cell membranes have been identified and the structure of the interior, cell membrane section, and now, finally after more than a decade, the extra-membrane structure of receptor (Australian researchers announced the work 2Q 2006).

Two types of tissues are most strongly influenced by insulin, as far as the stimulation of glucose uptake is concerned: muscle cells (myocytes) and fat cells (adipocytes). The former are important because of their central role in movement, breathing, circulation, etc, and the latter because they accumulate excess food energy against future needs. Together, they account for about two-thirds of all cells in a typical human body.

Physiological effects[]

File:Insulin glucose metabolism.jpg

Effect of insulin on glucose uptake and metabolism. Insulin binds to its receptor (1) which in turn starts many protein activation cascades (2). These include: translocation of Glut-4 transporter to the plasma membrane and influx of glucose (3), glycogen synthesis (4), glycolysis (5) and fatty acid synthesis (6).

The actions of insulin on the global human metabolism level include:

  • Control of cellular intake of certain substances, most prominently glucose in muscle and adipose tissue (about ⅔ of body cells).
  • Increase of DNA replication and protein synthesis via control of amino acid uptake.
  • Modification of the activity of numerous enzymes.

The actions of insulin on cells include:

  • Increased glycogen synthesis – insulin forces storage of glucose in liver (and muscle) cells in the form of glycogen; lowered levels of insulin cause liver cells to convert glycogen to glucose and excrete it into the blood. This is the clinical action of insulin which is directly useful in reducing high blood glucose levels as in diabetes.
  • Increased fatty acid synthesis – insulin forces fat cells to take in blood lipids which are converted to triglycerides; lack of insulin causes the reverse.
  • Increased esterification of fatty acids – forces adipose tissue to make fats (i.e., triglycerides) from fatty acid esters; lack of insulin causes the reverse.
  • Decreased proteolysis – decreasing the breakdown of protein.
  • Decreased lipolysis – forces reduction in conversion of fat cell lipid stores into blood fatty acids; lack of insulin causes the reverse.
  • Decreased gluconeogenesis – decreases production of glucose from non-sugar substrates, primarily in the liver (remember, the vast majority of endogenous insulin arriving at the liver never leaves the liver); lack of insulin causes glucose production from assorted substrates in the liver and elsewhere.
  • Decreased autophagy - decreased level of degradation of damaged organelles. Postprandial levels inhibit autophagy completely. [10]
  • Increased amino acid uptake – forces cells to absorb circulating amino acids; lack of insulin inhibits absorption.
  • Increased potassium uptake – forces cells to absorb serum potassium; lack of insulin inhibits absorption. Thus lowers potassium levels in blood.
  • Arterial muscle tone – forces arterial wall muscle to relax, increasing blood flow, especially in micro arteries; lack of insulin reduces flow by allowing these muscles to contract.
  • Increase in the secretion of hydrochloric acid by Parietal cells in the stomach.

Degradation[]

Once an insulin molecule has docked onto the receptor and effected its action, it may be released back into the extracellular environment or it may be degraded by the cell. Degradation normally involves endocytosis of the insulin-receptor complex followed by the action of insulin degrading enzyme. Most insulin molecules are degraded by liver cells. It has been estimated that a insulin molecule that is produced endogenously by the pancreatic beta cells is degraded within approximately one hour after its initial release into circulation (insulin half-life ~ 70 minutes).[11]

Hypoglycemia[]

Main article: Hypoglycemia

Although other cells can use other fuels for a while (most prominently fatty acids), neurons depend on glucose as a source of energy in the non-starving human. They do not require insulin to absorb glucose, unlike muscle and adipose tissue, and they have very small internal stores of glycogen. Glycogen stored in liver cells (unlike glycogen stored in muscle cells) can be converted to glucose, and released into the blood, when glucose from digestion is low or absent, and the glycerol backbone in triglycerides can also be used to produce blood glucose.

Sufficient lack of glucose and scarcity of these sources of glucose can dramatically make itself manifest in the impaired functioning of the central nervous system; dizziness, speech problems, and even loss of consciousness, can occur. Low glucose is known as hypoglycemia or, in cases producing unconsciousness, "hypoglycemic coma" (sometimes termed "insulin shock" from the most common causative agent). Endogenous causes of insulin excess (such as an insulinoma) are very rare, and the overwhelming majority of insulin-excess induced hypoglycemia cases are iatrogenic and usually accidental. There have been a few reported cases of murder, attempted murder, or suicide using insulin overdoses, but most insulin shocks appear to be due to errors in dosage of insulin (e.g., 20 units of insulin instead of 2) or other unanticipated factors (didn't eat as much as anticipated, or exercised more than expected, or unpredicted kinetics of the subcutaneously injected insulin itself).

Possible causes of hypoglycemia include:

  • External insulin (usually injected subcutaneously).
  • Oral hypoglycemic agents (e.g., any of the sulfonylureas, or similar drugs, which increase insulin release from beta cells in response to a particular blood glucose level).
  • Ingestion of low-carbohydrate sugar substitutes (animal studies show these can trigger insulin release (albeit in much smaller quantities than sugar) according to a report in Discover magazine, August 2004, p 18, although this is only an issue in people who do not have diabetes, or those who have type 2 diabetes because type 1 diabetes is caused by a complete absence of insulin. As a result, this can never be a cause of hypoglycemia in patients with type 1 diabetes since there is no endogenous insulin production to stimulate.

Diseases and syndromes[]

There are several conditions in which insulin disturbance is pathologic:

  • Diabetes mellitus – general term referring to all states characterized by hyperglycemia.
    • Type 1 – autoimmune-mediated destruction of insulin producing beta cells in the pancreas resulting in absolute insulin deficiency.
    • Type 2 – multifactoral syndrome with combined influence of genetic susceptibility and influence of environmental factors, the best known being obesity, age, and physical inactivity, resulting in insulin resistance in cells requiring insulin for glucose absorption. This form of diabetes is strongly inherited.
    • Other types of impaired glucose tolerance (see the diabetes article).
  • Insulinoma - a tumor of pancreatic beta cells producing excess of insulin or reactive hypoglycemia.
  • Metabolic syndrome – a poorly understood condition first called Syndrome X by Gerald Reaven, Reaven's Syndrome after Reaven, CHAOS in Australia (from the signs which seem to travel together), and sometimes prediabetes. It is currently not clear whether these signs have a single, treatable cause, or are the result of body changes leading to type 2 diabetes. It is characterized by elevated blood pressure, dyslipidemia (disturbances in blood cholesterol forms and other blood lipids), and increased waist circumference (at least in populations in much of the developed world). The basic underlying cause may be the insulin resistance of type 2 diabetes which is a diminished capacity for insulin response in some tissues (e.g., muscle, fat) to respond to insulin. Commonly, morbidities such as essential hypertension, obesity, Type 2 diabetes, and cardiovascular disease (CVD) develop.
  • Polycystic ovary syndrome – a complex syndrome in women in the reproductive years where there is anovulation and androgen excess commonly displayed as hirsutism. In many cases of PCOS insulin resistance is present.

As a medication[]

Main article: Insulin therapy

Synthetic "human" insulin is now manufactured for widespread clinical use using genetic engineering techniques using recombinant DNA technology. More recently, researchers have succeeded in introducing the gene for human insulin into plants and in producing insulin in plants, specifically safflower.[12][13] It is anticipated that this technique will reduce production costs.

Several of these are slightly modified versions of human insulin which, while having a clinical effect on blood glucose levels as though they were exact copies, but have been designed to have somewhat different absorption or duration of action characteristics. They are usually referred to as 'insulin analogs'. For instance, the first available, insulin lispro, does not exhibit a delayed absorption effect found in 'regular' insulin, and begins to have effect in as little as 15 minutes. Using it therefore does not require the pre-planning required for other insulins which begin to take effect much later (up to many hours) after administration. Another type is extended release insulin; the first of these was 'insulin glargine'. These have a steady effect for the entire time they are active, without the peak and droop of effect in other insulins; typically, they continue to have an insulin effect for an extended period from 18 to 24 hours.

Unlike many medicines, insulin currently cannot be taken orally. Like nearly all other proteins introduced into the gastrointestinal tract, it is reduced to fragments (even single amino acid components), whereupon all 'insulin activity' is lost. There has been some research into ways to protect insulin from the digestive tract, so that it can be administered orally or sublingually. While experimental, several companies now have various formulations in human clinical trials, which if successful, could see commercialization in several years.

Insulin is usually taken as subcutaneous injections by single-use syringes with needles, an insulin pump, or by repeated-use insulin pens with needles.
