Full resolution(1,693 × 1,024 pixels, file size: 70 KB, MIME type: image/png)
  • Beschreibung: schematischer Aufbau einer Röntgen-Röhre
  • Quelle: eigene Zeichnung
  • Fotograf oder Zeichner: HMilch
  • Lizenzstatus: PD


LegendEdit


Symbol English Deutsch Français Русский Português Polski Magyar Suomi
X X-Ray Röntgenstrahlen Rayons X Рентгеновское излучение Raio X Promieniowanie X Röntgen sugarak Röntgenputki
K Cathode (and heating-coil) Kathode (und Heizspule) Catode (et radiateur) Катод Bobina de Aquecimento do Catodo Katoda (i grzałka) katód Katodi
A Anode Anode Anode Антикатод Anodo Anoda knód Anodi
W_{in} water in Wassereingang Entrée d'eau Ввод охлаждающей воды Entrada De Água Wlot wody víz be Vesi sisään
W_{out} water out Wasserausgang Sortie d'eau Вывод охлаждающей воды Saida de Água Wylot wody víz ki Vesi ulos
C water cooler Wasserkühler Refrigerant à eau Водяное охлаждение Refrigerador à Água Chłodnica vízhűtés Vesijäähdytin
U_h Cathode-heater-voltage Kathode-Heizspannung Catode-haute-tension Напряжение подогревателя Voltagem-Aquecedor-Catodo Napięcie katodowe katód-fűtőfeszültség Katodijännite
U_a Anode-voltage Anodespannung Anode-tension Антикатодное напряжение Voltagem do Anodo Napięcie anodowe anódfeszültség Anodijännite
